- Romeo ESP32-C3 Robot Control Board (Supports Wi-Fi & Bluetooth 5)
- Integrates Wi-Fi & Bluetooth 5 with ESP32-C3 module
- Supports IPS TFT display for clear visuals
- Provides dual control for servos and motors
- Features 9 Gravity IO interfaces for versatility
- Compact design measuring 47×38.5mm
The Romeo ESP32-C3 Robot Control Board (Supports Wi-Fi & Bluetooth 5) is a compact and integrated motor driver development board featuring an onboard ESP32-C3 module. It supports an IPS TFT display screen and offers dual control schemes for servos and motors. With 9 IO interfaces compatible with the Gravity standard, it can connect to various Gravity sensor modules. The servo interface provides a stable power supply for high-current devices, and a built-in GDI interface allows for IPS display connectivity, making it suitable for comprehensive robotics projects.
- 1x Romeo mini Control Board (ESP32-C3)
- 47 x 38.5 mm
- Main control chip: ESP32-C3-MINI-1
- Type-C input voltage: 5V
- VIN input voltage range: 5-12V
- Motor output current: 1.7A continuous per channel
- Servo input voltage range: 5 – 12V
- Digital I/O ports: 4
- Analog I/O ports: 3
- UART ports: 1
- I2C ports: 1
- Motor ports: 2
- GDI ports: 1
- Type-C ports: 1
